Agent and Skill Workflow¶

The 8-step infrastructure development workflow.

Overview¶

Agentic InfraOps uses a multi-agent orchestration system where specialized AI agents coordinate through artifact handoffs to transform Azure infrastructure requirements into deployed infrastructure code. The system supports dual IaC tracks — Bicep and Terraform — sharing common requirements, architecture, design, and governance steps (1-3.5) then diverging into track-specific planning, code generation, and deployment (steps 4-6) before converging again for documentation (step 7).

The InfraOps Conductor (🎼 Maestro, also referred to as the Coordinator) orchestrates the complete workflow, routing to Bicep or Terraform agents based on the iac_tool field in 01-requirements.md, while enforcing mandatory approval gates.

Quick Start

Press Ctrl+Shift+I to open Copilot Chat, select InfraOps Conductor, and describe your project. The Conductor handles all 8 steps with approval gates.

Formalized Workflow Engine¶

The workflow is defined as a machine-readable DAG (Directed Acyclic Graph) in .github/skills/workflow-engine/templates/workflow-graph.json. The Conductor reads this graph instead of relying on hardcoded step logic:

Nodes: agent-step, gate, subagent-fan-out, validation
Edges: dependency links with conditions (on_complete, on_skip, on_fail)
IaC routing: conditional edges route to Bicep or Terraform agents based on decisions.iac_tool
Fan-out: Step 7 substeps (cost estimate, runbook, etc.) can execute in parallel

The Conductor resolves agent paths and models via .github/agent-registry.json.

Agent Architecture¶

The Conductor Pattern¶

The Conductor (also called Coordinator) orchestrates the entire workflow by delegating to specialised agents step by step, enforcing approval gates, and maintaining session state. The following diagram shows the end-to-end flow:

sequenceDiagram
    autonumber
    participant U as 👤 User
    participant C as 🎼 Conductor Agent
    participant Agents as 🤖 Agents
    participant X as ⚔️ Challenger Agent

    Note over C: AI prepares · Humans decide

    U->>C: Describe infrastructure intent
    C->>Agents: 📋 Gather requirements
    Agents-->>C: 01-requirements.md
    C->>X: Challenge requirements
    X-->>C: Findings
    C->>U: Present for review

    rect rgba(255, 200, 0, 0.15)
    Note over U,C: 🛑 APPROVAL GATE
    U-->>C: ✅ Approve
    end

    C->>Agents: 🏛️ Architecture + 💰 Cost
    Agents-->>C: 02-assessment.md
    C->>X: Challenge architecture
    C->>U: Present for review

    rect rgba(255, 200, 0, 0.15)
    Note over U,C: 🛑 APPROVAL GATE
    U-->>C: ✅ Approve
    end

    C->>Agents: 📐 IaC Plan + Governance
    Note right of Agents: Bicep or Terraform track
    Agents-->>C: 04-plan.md + constraints
    C->>X: Challenge plan
    C->>U: Present for review

    rect rgba(255, 200, 0, 0.15)
    Note over U,C: 🛑 APPROVAL GATE
    U-->>C: ✅ Approve
    end

    C->>Agents: ⚒️ Generate IaC (AVM-first)
    Note right of Agents: lint → review → validate
    Agents-->>C: infra/{bicep,terraform}/{project}

    rect rgba(255, 200, 0, 0.15)
    Note over U,C: 🛑 APPROVAL GATE
    U-->>C: ✅ Approve for deploy
    end

    C->>Agents: 🚀 Deploy to Azure
    Note right of Agents: what-if / plan preview first
    Agents-->>C: 06-deployment-summary.md

    rect rgba(255, 200, 0, 0.15)
    Note over U,C: 🛑 VERIFICATION
    U-->>C: ✅ Verify resources
    end

    C->>Agents: 📚 Generate as-built docs
    Agents-->>C: 07-*.md documentation suite
    C->>U: Present complete documentation

    Note over U,Agents: ✅ AI Orchestrated · Human Governed · Azure Ready

Agent Delegation Graph¶

The detailed delegation graph below shows how the Conductor routes to each specialised agent and how subagents are invoked for validation:

%%{init: {'theme':'neutral'}}%%
graph TB
    subgraph "Orchestrator"
        COND["InfraOps Conductor<br/>🎼 Maestro"]
    end

    subgraph "Step 1: Requirements"
        REQ["requirements<br/>📜 Scribe"]
    end

    subgraph "Step 2: Architecture"
        ARCH["architect<br/>🏛️ Oracle"]
        MCP["💰 Azure Pricing MCP"]
    end

    subgraph "Step 3: Design Artifacts"
        DIAG["azure-diagrams<br/>🎨 Skill"]
        ADR["azure-adr<br/>📝 Skill"]
    end

    subgraph "Step 3.5: Governance"
        GOV["governance<br/>🛡️ Warden"]
    end

    subgraph "Step 4: Planning"
        BPLAN["bicep-plan<br/>📐 Strategist"]
        TPLAN["terraform-plan<br/>📐 Strategist"]
    end

    subgraph "Step 5: Implementation"
        BCODE["bicep-code<br/>⚒️ Forge"]
        BLINT["bicep-lint-subagent"]
        BWHATIF["bicep-whatif-subagent"]
        BREVIEW["bicep-review-subagent"]
        TCODE["terraform-code<br/>⚒️ Forge"]
        TLINT["terraform-lint-subagent"]
        TPLANSA["terraform-plan-subagent"]
        TREVIEW["terraform-review-subagent"]
    end

    subgraph "Step 6: Deployment"
        BDEP["bicep-deploy<br/>🚀 Envoy"]
        TDEP["terraform-deploy<br/>🚀 Envoy"]
    end

    subgraph "Step 7: Documentation"
        DOCS["azure-artifacts<br/>📚 Skill"]
    end

    COND -->|"delegates"| REQ
    COND -->|"delegates"| ARCH
    COND -->|"invokes"| DIAG
    COND -->|"invokes"| ADR
    COND -->|"delegates"| GOV
    COND -->|"Bicep track"| BPLAN
    COND -->|"Terraform track"| TPLAN
    COND -->|"Bicep track"| BCODE
    COND -->|"Terraform track"| TCODE
    BCODE -->|"validates"| BLINT
    BCODE -->|"validates"| BWHATIF
    BCODE -->|"validates"| BREVIEW
    TCODE -->|"validates"| TLINT
    TCODE -->|"validates"| TPLANSA
    TCODE -->|"validates"| TREVIEW
    COND -->|"Bicep track"| BDEP
    COND -->|"Terraform track"| TDEP
    COND -->|"invokes"| DOCS

    MCP -.->|"pricing data"| ARCH

    style COND fill:#8957E5,color:#fff
    style REQ fill:#e1f5fe
    style ARCH fill:#fff3e0
    style MCP fill:#fff9c4
    style DIAG fill:#f3e5f5
    style ADR fill:#e8eaf6
    style GOV fill:#fff3e0
    style BPLAN fill:#e8f5e9
    style TPLAN fill:#e8f5e9
    style BCODE fill:#fce4ec
    style TCODE fill:#fce4ec
    style BDEP fill:#c8e6c9
    style TDEP fill:#c8e6c9
    style DOCS fill:#e3f2fd

Agent Roster¶

Primary Orchestrator¶

Agent	Codename	Role	Model
InfraOps Conductor	🎼 Maestro	Master orchestrator for 8-step workflow	Claude Opus (latest)

Core Agents (8 Steps)¶

Steps 1-3.5 and 7 are shared. Steps 4-6 have Bicep and Terraform variants.

Step	Agent	Codename	Role	Artifact
1	`requirements`	📜 Scribe	Captures infrastructure requirements	`01-requirements.md`
2	`architect`	🏛️ Oracle	WAF assessment and design decisions	`02-architecture-assessment.md`
3	`design`	🎨 Artisan	Diagrams and ADRs	`03-des-*.md/.py/.png`
3.5	`governance`	🛡️ Warden	Policy discovery and compliance	`04-governance-constraints.md/.json`
4b	`bicep-plan`	📐 Strategist	Bicep implementation planning	`04-implementation-plan.md` + `04-*-diagram.py/.png`
4t	`terraform-plan`	📐 Strategist	Terraform implementation planning	`04-implementation-plan.md` + `04-*-diagram.py/.png`
5b	`bicep-code`	⚒️ Forge	Bicep template generation	`infra/bicep/{project}/`
5t	`terraform-code`	⚒️ Forge	Terraform configuration generation	`infra/terraform/{project}/`
6b	`bicep-deploy`	🚀 Envoy	Bicep deployment	`06-deployment-summary.md`
6t	`terraform-deploy`	🚀 Envoy	Terraform deployment	`06-deployment-summary.md`
7	`as-built`	📚 Chronicler	Post-deployment documentation suite	`07-*.md`

Validation Subagents¶

Bicep track:

Subagent	Purpose	Invoked By
`bicep-lint-subagent`	Syntax validation (`bicep lint`, `bicep build`)	`bicep-code`
`bicep-whatif-subagent`	Deployment preview (`az deployment what-if`)	`bicep-code`, `bicep-deploy`
`bicep-review-subagent`	Code review (AVM, security, naming)	`bicep-code`

Terraform track:

Subagent	Purpose	Invoked By
`terraform-lint-subagent`	Syntax validation (`terraform validate`, `fmt`)	`terraform-code`
`terraform-plan-subagent`	Deployment preview (`terraform plan`)	`terraform-code`
`terraform-review-subagent`	Code review (AVM-TF, security, naming)	`terraform-code`

Standalone Agents¶

Agent	Codename	Role
`challenger`	⚔️ Challenger	Adversarial reviewer — challenges architecture, plans, and code
`diagnose`	🔍 Sentinel	Resource health assessment and troubleshooting

Approval Gates¶

The Conductor enforces mandatory pause points for human oversight:

Never Skip Gates

Gates are non-negotiable. Skipping approval gates can lead to deploying infrastructure that violates governance policies or security baselines.

Gate	After Step	User Action
Gate 1	Requirements (Step 1)	Confirm requirements complete
Gate 2	Architecture (Step 2)	Approve WAF assessment
Gate 2.5	Governance (Step 3.5)	Approve governance constraints
Gate 3	Planning (Step 4)	Approve implementation plan
Gate 4	Pre-Deploy (Step 5)	Approve lint/what-if/review results
Gate 5	Post-Deploy (Step 6)	Verify deployment

Workflow Steps¶

Step 1: Requirements (📜 Scribe)¶

Agent: requirements

Gather infrastructure requirements through interactive conversation.

Invoke: Ctrl+Shift+A → requirements
Output: agent-output/{project}/01-requirements.md

Captures:

Functional requirements (what the system does)
Non-functional requirements (performance, availability, security)
Compliance requirements (regulatory, organizational)
Budget constraints

Handoff: Passes context to architect agent.

Step 2: Architecture (🏛️ Oracle)¶

Agent: architect

Evaluate requirements against Azure Well-Architected Framework pillars.

Invoke: Ctrl+Shift+A → architect
Output: agent-output/{project}/02-architecture-assessment.md

Features:

WAF pillar scoring (Reliability, Security, Cost, Operations, Performance)
SKU recommendations with real-time pricing (via Azure Pricing MCP)
Architecture decisions with rationale
Risk identification and mitigation

Handoff: Suggests azure-diagrams skill or IaC planning agent (bicep-plan / terraform-plan).

Step 3: Design Artifacts (🎨 Artisan | Optional)¶

Skills: azure-diagrams, azure-adr

Create visual and textual design documentation.

Trigger: "Create an architecture diagram for {project}"
Output: agent-output/{project}/03-des-diagram.py, 03-des-adr-*.md

Diagram types: Azure architecture, business flows, ERD, timelines

ADR content: Decision, context, alternatives, consequences

Step 3.5: Governance (🛡️ Warden)¶

Agent: governance (04g-Governance)

Discover Azure Policy constraints and produce governance artifacts.

Invoke: Ctrl+Shift+A → governance
Output: agent-output/{project}/04-governance-constraints.md, 04-governance-constraints.json

Features:

Azure Policy REST API discovery via governance-discovery-subagent
Policy effect classification (Deny, Audit, Modify, DeployIfNotExists)
Dual-track property mapping (bicepPropertyPath + azurePropertyPath)

Approval Gate

The user must approve governance constraints before proceeding to planning.

Step 4: Planning (📐 Strategist)¶

Agent: bicep-plan (Bicep track) or terraform-plan (Terraform track)

Create detailed implementation plan using governance constraints as input.

BicepTerraform

Invoke: Ctrl+Shift+A → bicep-plan
Output: agent-output/{project}/04-implementation-plan.md

Invoke: Ctrl+Shift+A → terraform-plan
Output: agent-output/{project}/04-implementation-plan.md

Prerequisites: 04-governance-constraints.md/.json from Step 3.5

Features:

Governance constraints integration from Step 3.5
AVM module selection (Bicep: br/public:avm/res/, Terraform: AVM-TF registry)
Resource dependency mapping
Auto-generated Step 4 diagrams (04-dependency-diagram.py/.png and 04-runtime-diagram.py/.png)
Naming convention validation (CAF)
Phased implementation approach

Approval Gate

The user must approve the implementation plan before proceeding to code generation.

Step 5: Implementation (⚒️ Forge)¶

Agent: bicep-code (Bicep track) or terraform-code (Terraform track)

Generate IaC templates following Azure Verified Modules standards.

BicepTerraform

Invoke: Ctrl+Shift+A → bicep-code
Output: infra/bicep/{project}/main.bicep, modules/

Invoke: Ctrl+Shift+A → terraform-code
Output: infra/terraform/{project}/main.tf, modules/

Both tracks also produce agent-output/{project}/05-implementation-reference.md.

Standards (shared across both tracks):

AVM-first approach (Bicep: public registry; Terraform: AVM-TF registry)
Unique suffix for global resource names
Required tags on all resources
Security defaults (TLS 1.2, HTTPS-only, managed identity)
Phase 1.5 governance compliance mapping from 04-governance-constraints.json

Preflight Validation (via track-specific subagents):

Bicep Subagent	Terraform Subagent	Validation
`bicep-lint-subagent`	`terraform-lint-subagent`	Syntax check, linting rules
`bicep-whatif-subagent`	`terraform-plan-subagent`	Deployment preview
`bicep-review-subagent`	`terraform-review-subagent`	AVM compliance, security scan

Approval Gate

The user must approve preflight validation results before deployment.

Step 6: Deployment (🚀 Envoy)¶

Agent: bicep-deploy (Bicep track) or terraform-deploy (Terraform track)

Execute Azure deployment with preflight validation.

BicepTerraform

Invoke: Ctrl+Shift+A → bicep-deploy
Output: agent-output/{project}/06-deployment-summary.md

Bicep features: bicep build validation, az deployment group what-if analysis, deployment execution via deploy.ps1, post-deployment resource verification.

Invoke: Ctrl+Shift+A → terraform-deploy
Output: agent-output/{project}/06-deployment-summary.md

Terraform features: terraform validate and terraform fmt -check, terraform plan preview, phase-aware deployment via bootstrap.sh and deploy.sh, post-deployment resource verification.

Approval Gate

The user must verify deployed resources before proceeding to documentation.

Step 7: Documentation (📚 Skills)¶

Skill: azure-artifacts

Generate comprehensive workload documentation.

Trigger: "Generate documentation for {project}"
Output: agent-output/{project}/07-*.md

Document Suite:

File	Purpose
`07-documentation-index.md`	Master index with links
`07-design-document.md`	Technical design documentation
`07-operations-runbook.md`	Day-2 operational procedures
`07-resource-inventory.md`	Complete resource listing
`07-ab-cost-estimate.md`	As-built cost analysis
`07-compliance-matrix.md`	Security control mapping
`07-backup-dr-plan.md`	Disaster recovery procedures

Complexity Classification¶

The Requirements agent classifies project complexity based on scope. The Conductor validates the classification. Complexity drives the number of adversarial review passes at Steps 1, 2, 4, and 5.

Tier	Criteria
Simple	≤3 resource types, single region, no custom Azure Policy, single environment
Standard	4–8 resource types, multi-region OR multi-env (not both), ≤3 custom policies
Complex	>8 resource types, multi-region + multi-env, >3 custom policies, hub-spoke

Adversarial Review Matrix¶

Reviews target AI-generated creative decisions (architecture, plan, code) — not machine-discovered data (governance) or Azure tool output (what-if).

Complexity	Step 1 (Req)	Step 2 (Arch)	Step 4 (Plan)	Step 5 (Code)
simple	1×	1×	1×	1×
standard	1×	2× (→3×)	2×	2× (→3×)
complex	1×	3×	2×	3×

Conditional passes: "(→3×)" means pass 3 only runs if pass 2 returned ≥1 must_fix. Plan reviews are capped at 2 passes because the cost-feasibility lens was already applied at Step 2.

Steps without review: Design (3), Governance (3.5), Deploy (6), As-Built (7). Governance is machine-discovered; deploy previews are validated by Azure tooling; the human approves at each gate.

Agents vs Skills¶

Aspect	Agents	Skills
Invocation	Manual (`Ctrl+Shift+A`) or via Conductor	Automatic or explicit
Interaction	Conversational with handoffs	Task-focused
State	Session context	Stateless
Output	Multiple artifacts	Specific outputs
When to use	Core workflow steps	Specialized capabilities

Quick Reference¶

Using the Conductor (Recommended)¶

1. Ctrl+Shift+I → Select "InfraOps Conductor"
2. Describe your infrastructure project
3. Follow guided workflow through all 8 steps with approval gates

Direct Agent Invocation¶

1. Ctrl+Shift+A → Select specific agent
2. Provide context for that step
3. Agent produces artifacts and suggests next step

Skill Invocation¶

Automatic: Skills activate based on prompt keywords:

"Create an architecture diagram" → azure-diagrams skill
"Document the decision to use AKS" → azure-adr skill

Explicit: Reference the skill by name:

"Use the azure-artifacts skill to generate documentation"

Artifact Naming Convention¶

Step	Prefix	Example
Requirements	`01-`	`01-requirements.md`
Architecture	`02-`	`02-architecture-assessment.md`
Design	`03-des-`	`03-des-diagram.py`, `03-des-adr-0001-*.md`
Planning	`04-`	`04-implementation-plan.md`, `04-governance-constraints.md`
Implementation	`05-`	`05-implementation-reference.md`
Deployment	`06-`	`06-deployment-summary.md`
As-Built	`07-`	`07-design-document.md`, `07-ab-diagram.py`
Diagnostics	`08-`	`08-resource-health-report.md`

Next Steps¶

Prompt Guide — ready-to-use prompts for every agent and skill
Quickstart — 10-minute getting started walkthrough
