Quickstart

Get running in 10 minutes.

Template repository

You do not clone this repository directly. Instead, you create your own repository from the Accelerator template, which gives you a clean starting point with all agents, skills, and dev container configuration ready to go.

Prerequisites

What you need

Items marked ⭐ are required for learning. An Azure subscription is optional — you only need it when deploying to Azure in Step 6.

Requirement	How to Get
⭐ GitHub account	Sign up
⭐ GitHub Copilot license	Business or Enterprise required — see plans
⭐ GitHub fine-grained PAT	Required for devcontainer GitHub auth via GH_TOKEN
⭐ VS Code	Download
⭐ Docker Desktop	Download
Azure subscription	Optional — required only for Step 6 deployment

Docker is required

A Docker-compatible runtime is needed for the dev container. Docker Desktop is the most common choice. Free alternatives include Rancher Desktop, Colima (macOS), and Podman (Linux/macOS). See Dev Container Setup for detailed installation options.

If the dev container fails to build

1. Check the VS Code terminal for error messages
2. Verify Docker is running (docker ps should succeed)
3. Follow recovery steps in Dev Container Setup and Troubleshooting

Most setup failures happen before APEX itself starts.

Configure GH_TOKEN before you open the container

GitHub operations inside the devcontainer depend on a fine-grained Personal Access Token exposed as GH_TOKEN through VS Code User Settings. Shell exports inside the container are not reliable and do not survive rebuilds. The full setup is documented on Dev Container Setup, but the minimum working configuration is included below so you do not miss it.

Step 1: Create Your Repository from the Template

1. Go to the Accelerator template repository
2. Click the green “Use this template” button → “Create a new repository”
3. Choose an owner and repository name (e.g. my-infraops-project)
4. Select Public or Private visibility
5. Click Create repository

What is a template repository?

A GitHub template repository creates a brand-new repository with the same directory structure and files — but with a clean commit history and no fork relationship. Your repo is entirely yours.

Step 2: Clone and Open

Clone your new repository (not this upstream project):

git clone https://github.com/YOUR-USERNAME/my-infraops-project.git # (1)!
code my-infraops-project

1. Replace YOUR-USERNAME/my-infraops-project with your actual GitHub username and the repository name you chose in Step 1.

Step 3: Open in Dev Container

What is a dev container?

A dev container is a pre-configured development environment that runs inside a Docker container. It ensures every contributor has identical tools, extensions, and settings — no manual setup required. See the Dev Container Setup page for details.

1. Press F1 (or Ctrl+Shift+P)
2. Type: Dev Containers: Reopen in Container
3. Wait 3-5 minutes for setup

The Dev Container installs all tools automatically:

• Azure CLI + Bicep CLI
• Terraform CLI + TFLint
• PowerShell 7
• Python 3 + diagrams library
• Go (Terraform MCP server)
• apex-recall CLI (session recall)
• Comprehensive set of VS Code extensions

Step 4: Set Up Azure (Optional)

If you plan to deploy to Azure or run the governance baseline workflow, configure your Azure environment with a single command:

npm run setup

This creates an Entra ID app registration, OIDC federated credentials, RBAC roles, and GitHub secrets/variables. See Azure Setup for details and manual alternatives.

Skip this if you are just learning

Azure setup is only required for Step 6 (Deploy) and the governance baseline workflow. You can explore the full agent workflow without it.

Step 5: Configure GH_TOKEN for the Dev Container

This step is easy to miss, but it is required for reliable GitHub CLI and repository operations in the devcontainer.

Use VS Code User Settings, not export GH_TOKEN=...

Set GH_TOKEN in VS Code User Settings so the devcontainer can forward it automatically. Adding it in .bashrc, .profile, or an in-container shell session does not persist reliably.

1. Create a fine-grained GitHub Personal Access Token
2. Grant at least these permissions:

Permission	Level
Contents	Read/Write
Metadata	Read
Pull requests	Read/Write
Issues	Read/Write
Workflows	Read/Write

1. Open VS Code User Settings (JSON)
2. Add this entry and replace the placeholder token value:

"terminal.integrated.env.linux": { "GH_TOKEN": "github_pat_your_token_here" }

1. Rebuild the devcontainer: F1 → Dev Containers: Rebuild Container
2. Run gh auth status inside the container and confirm it shows a logged-in token-based session

See Dev Container Setup for the full explanation, screenshots, and token rotation guidance.

Step 6: Verify Setup

Verify all tools installed correctly

Run these commands to confirm the dev container has all required CLIs and GitHub authentication:

gh auth status
az --version && bicep --version && terraform --version && pwsh --version # (1)!

1. gh auth status should show a token-backed login, and all four CLIs should print version numbers. If any fail, rebuild or reopen the dev container.

Step 7: Enable Subagent Orchestration

Required

The Orchestrator pattern requires this setting.

Without this setting, the Orchestrator cannot delegate to specialized agents, so multi-step workflows will stall after the first response.

Add this to your VS Code User Settings (Ctrl+, → Settings JSON):

{
  "chat.customAgentInSubagent.enabled": true // (1)!
}

1. This must be in User Settings, not Workspace Settings. Experimental features require user-level configuration.

Why User Settings? Workspace settings exist in .vscode/settings.json, but user settings take precedence for experimental features like subagent invocation.

Verify it’s enabled:

1. Open Command Palette (Ctrl+Shift+P)
2. Type: Preferences: Open User Settings (JSON)
3. Confirm the setting is present

Step 8: Start the Orchestrator

Option A: Orchestrator (Recommended)

The Orchestrator (🧠 Orchestrator) orchestrates the complete multi-step workflow:

1. Press Ctrl+Shift+I to open Copilot Chat
2. Select Orchestrator from the agent dropdown
3. Describe your project:

Create a simple web app in Azure with:
- App Service for web frontend
- Azure SQL Database for data
- Key Vault for secrets
- Region: swedencentral
- Environment: dev
- Project name: my-webapp

The Orchestrator guides you through all steps with approval gates.

Option B: Direct Agent Invocation

Invoke agents directly for specific tasks:

1. Press Ctrl+Shift+A to open the agent picker
2. Select the specific agent (e.g., requirements)
3. Enter your prompt

Step 9: Follow the Workflow

The agents work in sequence with handoffs. Steps 1-3.5 and 7 are shared; steps 4-6 route to Bicep or Terraform agents based on your iac_tool selection in Step 1. During requirements gathering, the Requirements agent asks which IaC tool you prefer — this choice determines which planning, code generation, and deployment agents the Orchestrator invokes.

Each agent has a thematic codename for easy reference in documentation and prompts.

Step	Agent	Codename	What Happens
1	requirements	📜 Scribe	Captures requirements
2	architect	🏛️ Oracle	WAF assessment
3	design	🎨 Artisan	Diagrams/ADRs (optional)
3.5	governance	🛡️ Warden	Policy discovery/compliance
4	iac-planner	📐 Strategist	Implementation plan
5	bicep-codegen / terraform-codegen	⚒️ Forge	IaC templates
6	bicep-deploy / terraform-deploy	🚀 Envoy	Azure deployment
7	as-built	📚 Chronicler	Documentation suite

Approval Gates: The Orchestrator pauses at key points:

• ⛔ Gate 1: After requirements (Step 1) — confirm requirements
• ⛔ Gate 2: After architecture (Step 2) — approve WAF assessment
• ⛔ Gate 2.5: After governance (Step 3.5) — approve governance constraints
• ⛔ Gate 3: After planning (Step 4) — approve implementation plan
• ⛔ Gate 4: After validation (Step 5) — approve preflight results
• ⛔ Gate 5: After deployment (Step 6) — verify resources

If a gate rejects your proposal

If the Challenger or an approval gate produces must_fix findings, return to the previous step, update your approach based on the feedback, and re-run. The Orchestrator will re-execute the step and re-trigger the gate. Use the artifact files in agent-output/{project}/ to understand what was flagged.

If a Step Fails

• Governance returns no policies: continue if 04-governance-constraints.json shows discovery_status: "COMPLETE". An empty policy list means no deny-effect constraints were found for that scope.
• Pricing, auth, or tooling fails: fix the environment first, then resume the same step. Start with Troubleshooting and Dev Container Setup.
• Security or cost findings block progress: update the generated plan or code, then re-run the same step with the exact failing output so the agent can repair it.

Before you deploy, review the mandatory guidance in Security Baseline and Cost Governance.

What You’ve Created

After completing the workflow:

agent-output/my-webapp/
├── 01-requirements.md          # Captured requirements (includes iac_tool)
├── 02-architecture-assessment.md  # WAF analysis
├── 03-des-diagram.drawio         # Optional Step 3 architecture diagram
├── 04-implementation-plan.md   # Phased plan
├── 04-dependency-diagram.py        # Step 4 dependency diagram
├── 04-runtime-diagram.py           # Step 4 runtime diagram
├── 04-governance-constraints.md   # Policy discovery
├── 05-implementation-reference.md # Module inventory
├── 06-deployment-summary.md    # Deployed resources
└── 07-*.md                     # Documentation suite

# Bicep track output:
infra/bicep/my-webapp/
├── main.bicep                  # Entry point
├── main.bicepparam             # Parameters
└── modules/
    ├── app-service.bicep
    ├── sql-database.bicep
    └── key-vault.bicep

# — OR — Terraform track output:
infra/terraform/my-webapp/
├── main.tf                     # Entry point
├── variables.tf                # Input variables
├── outputs.tf                  # Outputs
├── terraform.tfvars            # Variable values
└── modules/
    ├── app-service/
    ├── sql-database/
    └── key-vault/

Next Steps

Goal	Resource
Understand the full workflow	workflow.md
Try a guided hands-on challenge	MicroHack
Try a complete workflow	Prompt Guide
Review mandatory guardrails	Security Baseline and Cost Governance
Generate architecture diagrams	Use drawio skill (or python-diagrams for charts)
Create documentation	Use azure-artifacts skill
Explore Terraform patterns	Use terraform-patterns skill
Troubleshoot issues	troubleshooting.md
Contribute to the upstream repo	azure-agentic-infraops

Quick Reference

Orchestrator (Orchestrated Workflow)

Ctrl+Shift+I → Orchestrator → Describe project → Follow gates

Direct Agent Invocation

Ctrl+Shift+A → Select agent → Type prompt → Approve

Skill Invocation

Skills activate automatically based on your prompt:

• “Create an architecture diagram” → drawio
• “Generate an ADR” → azure-adr
• “Create workload documentation” → azure-artifacts

Or invoke explicitly:

Use the drawio skill to create a diagram for my-webapp
